Description
Brief Introduction
YA series circular vibrating screen is a multilayer, high-efficient screening machine for classification, separation, grading. It is widely used in chemical, coal dressing, mineral ore dressing, building material, hydropower, light, construction industries, etc
Main Features
1. Vibrating screen outer side plate bending using block pattern, tube beam and side panels connected with high strength bolts, machine without welding, structural stiffness and strength very good.
2.The machine utilizes eccentric block as exciting force
3. Large separation sizes up to approx. 100 mm
4. Flexible Coupling
5. Side plate’s material is Q235A or Q245A, thickness can be 8~10 mm.
6. The screen clothing can be woven wire mesh, perforated plate, rubber sheet, polyurethane plate or else, that depends on the material and customer requirements.
Type | Net layers | Net area(m2) | Vibrating Frequency (r/min) | Double amplitude (mm) | Power (KW) | Capacity(t/h) | Theoretical weight(t) |
YA1860 | 1 | 10.8 | 960 | 5 -8 | 7.5 | 120-240 | 2.4 |
YA2060 | 1 | 12 | 7.5 | 150-260 | 2.6 | ||
YA2260 | 1 | 13.2 | 7.5 | 180-280 | 3 | ||
YA2460 | 1 | 14.4 | 7.5 | 210-300 | 3.3 | ||
2YA1560 | 2 | 8 | 7.5 | 80-200 | 3.5 | ||
2YA1860 | 2 | 10.8 | 11 | 120-240 | 4 | ||
2YA2060 | 2 | 12 | 11 | 150-260 | 4.1 | ||
2YA2260 | 2 | 13.2 | 11 | 180-280 | 4.4 | ||
2YA2460 | 2 | 14.4 | 11 | 210-300 | 4.7 | ||
3YA1560 | 3 | 8 | 15 | 80-200 | 4.8 | ||
3YA1860 | 3 | 10.8 | 15 | 120-240 | 5 | ||
3YA2060 | 3 | 12 | 15 | 150-260 | 5.1 | ||
3YA2260 | 3 | 13.2 | 15 | 180-280 | 5.2 | ||
3YA2460 | 3 | 14.4 | 15 | 210-300 | 5.3 | ||
4YA1860 | 4 | 10.8 | 18.5 | 120-240 | 5.7 | ||
4YA2060 | 4 | 12 | 18.5 | 150-260 | 5.8 | ||
4YA2260 | 4 | 13.2 | 18.5 | 180-280 | 6 | ||
4YA2460 | 4 | 14.4 | 22 | 210-300 | 6.2 | ||
5YA1560 | 5 | 8 | 15 | 80-200 | 5.2 | ||
5YA1860 | 5 | 10.8 | 15 | 120-240 | 5.4 | ||
5YA2060 | 5 | 12 | 15 | 150-260 | 5.6 |
Notice
Please provide us the following requirement, we will select suitable vibrating screen for you.
(a) The name of materials
(b) Aim of using: get rid of impurity, grading
(c) Treatment volume: kg /h, L/h.
(d) The specification of screen (mesh or mm).
(e) How long is the operation time every day?
